CRADLES:                  2@5,000LB. CAP. ; 72”DIA. X 18”WIDE
                                 1@10,000LB. CAP. ; 72”DIA. X 24”WIDE

REELS:                      1@2,500LB. CAP.
                                 1@10,000LB. CAP. ; 72” DIA X 24” WIDE


TOW MOTORS:           1 UP TO 8,000LB. CAP


CRANES:                    UP TP 5-TON CAPACITY


CNC:                         HURCO BMC 40 (3-AXIS) w/30 TOOL CHANGER
                                 TRAVEL: X 40”, Y 30”
                                 WORK TABLE: X 51.2, Y 27.6
                                 WORK TABLE CAP: 3,300 LBS.

                                 LAGUN            (2-AXIS)
                                 X AXIS: 30”    Y  AXIS: 12”
                                 WORK TABLE CAP: 750LBS.


                                 ACER               (2-AXIS)
                                 X AXIS: 30”     Y AXIS: 12”
                                 WORK TABLE CAP: 750LBS.


DRILL PRESSES:         BAICE CRANE
                                 YODOGAWA  (RADIAL 3’)
                                 KOVOSVIT    (RADIAL 4’)


WIRE EDM:                MITSUBISHI    (FX20K)
                                   TABLE – 25” X 31”
                                   TRAVEL – 13.78 X 19.7 X 11.8 HIGH
                                   TABLE CAP: 1,764 LBS.


GRINDERS:                HARIG (2)                  manual/dry               6” x 12”
                                 HARIG (1)                 manual/dry               6” x 18”
                                 BOYER SCHULTZ        manual/wet              8” x 18”
                                 KIKINDA                    automatic/wet          11.5” x 39”
                                 GALLMEYER-
                                 LIVINGSTON              automatic/wet          12 x 24”


HONING:                   SUNNEN                    .1875 – 1” size range


LATHES:                    SOUTH BEND             20”diameter x 30” length
                                 CLAUSING                 16”diameter x 40” length
                                 COLCHESTER             26” diameter x 7” length – DROP BED


VERTICAL SAWS:        GROB
                                 ROLL-IN


HORIZONTAL SAWS:   JOHNSON (CUT OFF)


MILLING MACHINES:   BRIDGEPORT (1)


KELLERING:               BRIDGEPORT TRUE – TRACE

                                 X AXIS: 20”  Y AXIS: 12”
                                 WORK TABLE CAP.:  500LBS.


                                             Q.A LAB


EQUIPMENT:              NUMEREX MANUAL CMM
                                 MODEL:CZI-FMF        TYPE: C100
                                 W/RENISHAW TP1^S PROBE
                                 CONNECTED TO PACK-MATE 386/25
                                      w/WINDOWS-95.
                                 SCHERR TUMICO: OPTICAL COMPARITOR
                                      MODEL #2-810


INDICATORS:              MISC. INSPECTION EQUIPMENT


GAGE BLOCKS/PINS:  STARRET GAGE BLOCKS Ser.# 1013762
                                 MITUTOYO GAGE BLOCKS Ser.# 970492
                                 MEYER GAGE PINS:    .11   - .060 Ser.# M-0 MINUS
                                                                 .061 - .250 Ser.# M-1 MINUS
                                                                 .251 - .500 Ser.# M-2 MINUS


SOFTWARE:               WINDOWS XP PROFESIONAL
                                 SOLID EDGE
                                 autoCAD2000/MECHANICAL DESKTOP 5.0
                                 SMARTCAM REL 11 – 3D MACHINING
                                 SMARTCAM REL 11 – 4 AXIS WIRE
                                 GIBBSCAM
                                 MICROSOFT OFFICE
